The Complete Guide to Simple Automation using Google Sheets Macros

Google Sheets Macros are small programs you create inside of Google Sheets without needing to write any code. They allow you to automate repetitive tasks. They work by recording your actions as you do something and saving these actions as a “recipe” that you can re-use again with a single click.

Sound good?

They sure are! Read on to learn how to use them, see some examples, discover their limitations and also see how they’re a great way into the wonderful world of Apps Script coding 😀

Contents

  1. What are Google Sheets macros?
  2. Why should you use macros?
  3. How to create your first macro
  4. Other options
  5. A peek under the hood of Google Sheets Macros
  6. Google Sheets Macros examples!
  7. Resources

Continue reading The Complete Guide to Simple Automation using Google Sheets Macros

Data Studio Connector fields get an update

The engineers at Google continue to roll out updates to Data Studio at a relentless and impressive pace.

Back in September they released community connectors, which allow you to connect any web service with an API to Data Studio for reporting.

Yesterday, they released an update which gives developers much more control over the connector fields in Data Studio, by allowing developers to define Data Types and Semantic Types with more granularity, in your Apps Script code.

Additionally, developers can now embed calculated fields into the connector’s schema too, so it’s not left up to the user to figure this out.

This is a huge improvement as it obviates the need for the end user to select the correct field settings (for example, which aggregation to use) and should therefore make it easier for users to build accurate reports.

Data Type and Semantic Type features in the connector fields

Continue reading Data Studio Connector fields get an update

Community Connectors: Access all your data in Google Data Studio 💥💥

Data Studio is relatively new dashboard tool from Google, launched in mid-2016. It’s a superb tool for creating professional looking reports, easily and quickly, and it connects seamlessly to other Google data sources (e.g. Analytics, AdSense, Sheets, …).

Here’s an introduction to Data Studio and a look at the more advanced features.

GitHub commit dashboard, built with the new native data Community Connector
GitHub commits dashboard, built in Data Studio using a native Data Connector

Do you work with data outside of Google’s ecosystem though?

I’ll go out on a limb here, and say, yes, most likely you do.

Perhaps you’re a digital marketing analyst looking at Facebook, Twitter, Instagram, MailChimp data (etc…) for example.

Many of us work with other web services and you want that data displayed in Data Studio. With the launch of native data Community Connectors, you can connect to your favorite web services and access data that lives outside the Google ecosystem directly!

What is a Data Studio Community Connector?

Data Studio Community Connector example
Data Studio Community Connector example with the MailChimp API (click to enlarge)

Continue reading Community Connectors: Access all your data in Google Data Studio 💥💥

Show data from the GitHub API in Google Sheets, using Apps Script and Oauth

This post shows you how to connect a Google Sheet to GitHub’s API, with Oauth and Apps Script. The goal is to retrieve data and information from GitHub and show it in your Google Sheet, for further analysis and visualization.

If you manage a development team or you’re a technical project manager, then this could be a really useful way of analyzing and visualizing your team’s or project’s coding statistics against goals, such as number of commits, languages, people involved etc. over time.

Contents

  1. What are Git and GitHub?
  2. Access GitHub API using Basic Authentication
  3. Access GitHub API using OAuth2 Authentication
  4. Resources and further reading

Note, this is not a post about integrating your Apps Script environment with GitHub to push/pull your code to GitHub. That’s an entirely different process, covered in detail here by Google Developer Expert Martin Hawksey.

Continue reading Show data from the GitHub API in Google Sheets, using Apps Script and Oauth

How to create an annotated line graph in Google Sheets

line graph in Google Sheets
Animated line chart in Google Sheets

This post looks at how to create a more advanced line graph in Google Sheets, with comparison lines and annotations, so that the viewer can absorb the maximum amount of insight from a single chart.

For fun, I’ll also show you how to animate this line graph in Google Sheets.

Want your own copy of this line graph?

Click here to access your copy of this template >>

This chart was originally developed for The Write Life during their 4-day product sale earlier this year. It featured as part of a dashboard that was linked to the E-junkie sales platform and displayed sales data in real-time:

Google Sheet e-junkie real-time dashboard
Google Sheet e-junkie real-time dashboard

As with any graph, we start with the data:

The data table

Line graph data table

The key to this line graph in Google Sheets is setting up the data table correctly, as this allows you to show an original data series (the grey lines in the animated GIF image), progress series lines (the colored lines in the animated GIF) and current data values (the data label on the series lines in the GIF).

In this example, I have date and times as my row headings, as I’m measuring data across a 4-day period, and sales category figures as column headings, as follows:

Annotated line graph data table

Red columns

The red column, labeled with 1 above, contains historic data from the 2015 sale.

Red column 2 is a copy of the same data but only showing the progress up to a specific point in time.

In red column 3, the following formula will create a copy of the last value in column 2, which is used to add a value label on the chart:

=IF(AND((C2+C3)=C2,C2<>0),C2,"")

Purple columns:

Purple columns 4,5 and 6 are exactly the same but for 2016 data. The formula in this case, in column 6, is:

=IF(AND((F2+F3)=F2,F2<>0),F2,"")

Green columns:

Data in green columns 7 and 8, is our current year data (2017), so in this case there is no column of historic data. The formula in column 8 for this example is:

=IF(AND((H2+H3)=H2,H2<>0),H2,"")

Creating the line graph in Google Sheets

Highlight your whole data table (Ctrl + A if you’re on a PC, or Cmd + A if you’re on a Mac) and select Insert > Chart from the menu.

In the Recommendations tab, you’ll see the line graph we’re after in the top-right of the selection. It shows the different lines and data points, so all that’s left to do is some formatting.

Line graph selection

Format the series lines as follows:

  • For the historic data (columns 1 and 4 in the data table), make light grey and 1px thick
  • For the current data (columns 2, 5 and 7 in the data table), choose colors and make 2px thick
  • For the “max” values (columns 3, 6 and 8 in the data table), match the current data colors, make the data point 7px and add data label values (see steps 1, 2 and 3 in the image below)

Line graph data labels

This is the same technique I’ve written about in more detail in this post:

How can I annotate data points in Google Sheets charts?

Animating the chart with Apps Script

How about creating an animated version of this chart?

Oh, go on then.

When this script runs, it collects the historic data, then adds that data back to each new row after a 10 millisecond delay (achieved with the Utilities.sleep method and the SpreadsheetApp.flush method to apply all pending changes).

I don’t make any changes to the graph or create any fancy script to change it, I leave that up to the Google Chart Tool. It just does its best to keep up with the changing data, although as you can see from the GIF at the top of this post, it’s not silky smooth.

By the way, you can create and modify charts with Apps Script (see this waterfall chart example, or this funnel chart example) or with the Google Chart API (see this animated temperature chart). This may well be a better route to explore to get a smoother animation, but I haven’t tried yet…

Here’s the script:

function startTimedData() {
  var ss = SpreadsheetApp.getActive();
  var sheet = ss.getSheetByName('Animated Chart');
  var lastRow = sheet.getLastRow()-12;

  var data2015 = sheet.getRange(13,2,lastRow,1).getValues(); // historic data
  var data2016 = sheet.getRange(13,5,lastRow,1).getValues(); // historic data

  // new data that would be inputted into the sheet manually or from API
  var data2017 = [[1],[7],[14],[19],[27],[32],[34],[36],[44],[49],[57],[65],[72],[76],[79],[86],[92],[99],[104],[109],[111],[112],[120],[128],[130],
                  [132],[133],[140],[144],[149],[151],[152],[158],[162],[170],[177],[179],[184],[188],[194],[200],[205],[211],[216],[224],[232],[238],
                  [241],[246],[248],[252],[259],[266],[268],[276],[284],[291],[299],[300],[301],[306],[311],[315],[316],[323],[324]];

  for (var i = 0; i < data2015.length;i++) {
    outputData(data2015[i],data2016[i],data2017[i],i);
  }

}

function outputData(d1,d2,d3,i) {
  var ss = SpreadsheetApp.getActive();
  var sheet = ss.getSheetByName('Animated Chart');

  sheet.getRange(13+i,3).setValue(d1);
  sheet.getRange(13+i,6).setValue(d2);
  sheet.getRange(13+i,8).setValue(d3);
  Utilities.sleep(10);
  SpreadsheetApp.flush();
}

function clearData() {
  var ss = SpreadsheetApp.getActive();
  var sheet = ss.getSheetByName('Animated Chart');
  var lastRow = sheet.getLastRow()-12;

  sheet.getRange(13,3,lastRow,1).clear();
  sheet.getRange(13,6,lastRow,1).clear();
  sheet.getRange(13,8,lastRow,1).clear();

}

On lines 6 and 7, the script grabs the historic data for 2015 and 2016 respectively. For the contemporary 2017 data, I’ve created an array in my script to hold those values, since they don’t exist in my spreadsheet table.

This code is available here on GitHub.

Finally, add a menu for access from your Google Sheet with the following code:

function onOpen() {
  var ui = SpreadsheetApp.getUi();

  ui.createMenu("Timed data")
    .addItem("Start","startTimedData")
    .addItem("Clear","clearData")
    .addToUi();
}

This allows you to run the Start and Clear functions directly from your Google Sheet browser tab, rather than the script editor tab.

That’s it. Hit Start and you should see your chart animate before your eyes:

Animated Apps Script chartAnimated Apps Script chart

If you look closely, you’ll also see the data populating your sheet.
