Use The Onion Method To Approach Complex Formulas

Complex Formulas? The Onion Method? Huh?

I’m talking about the idea that complex formulas in Google Sheets are a lot like onions.

They have layers.

And they sometimes make you cry. 🀣

The Onion Method For Complex Formulas

If you’re building complex formulas, then I advocate following a one-action-per-step approach.

What I mean by this is that you build your formulas in a series of steps, and only make one change with each step.

The Onion Method is a framework by which to approach hard formulas, and consists of these three elements:

  1. Put each new step of the formula in a new cell
  2. Label each step with a simple “Step 1”, “Step 2”, etc. in adjacent cells
  3. Change the background color of each formula cell, so they can be easily found

This lets you see the formula progress in an incremental way and is really helpful when you’re building or tyring to understand complex formulas.

Sometimes a step might result in an error (typically a #N/A or #REF!), but that’s ok, provided it gets fixed in a subsequent step, as shown in this SUMPRODUCT example:

Advanced Formula steps example

Each of these intermediary formulas in the above image moves us forward incrementally, until the final answer is obtained in step 6.

Similarly, if you’re trying to understand complex formulas, peel the layers back until you reach the core (which is hopefully a function you understand!). Then, build it back up in steps to get back to the full formula.

Example 1: Building A Complex Formula With The Onion Method

Let’s look at importing data from the table on this Wikipedia page of largest cities by population.

Wikipedia country data table

Step 0

Open a new Google Sheet (bonus points for using the browser shortcut and just typing Sheets.new into your browser window).

Step 1

Step 1 is a standard IMPORTHTML function to retrieve the city table from Wikipedia. In cell A2:

=IMPORTHTML("https://en.wikipedia.org/wiki/List_of_cities_proper_by_population","table",2)

The data has some issues, but it’s a start.

Import Wikipedia table into Google Sheets with IMPORTHTML

Step 2

In Step 2, we use the INDEX function to grab just the population column.

Per The Onion Method, we insert this next step in a new cell, cell J2, to the right of the existing data, in this example:

=INDEX(IMPORTHTML("https://en.wikipedia.org/wiki/List_of_cities_proper_by_population","table",2),,4)

Google Sheets Complex Formula Step 2

I’ve highlighted the new action step in red — adding the INDEX function wrapper.

Looking closely at that INDEX function wrapper, you’ll see that we’ve left the row argument blank, namely:

INDEX(data, ,4)

which returns the entire column.

We’ll deal with the population column on its own and come back to our main formula later.

Step 3

Hmm, that population column is messed up! Regex to the rescue!

Using the REGEXEXTRACT function, extract just the numbers and “,” from the data, before the citations in brackets:

=REGEXEXTRACT(INDEX(IMPORTHTML("https://en.wikipedia.org/wiki/List_of_cities_proper_by_population","table",2),,4),"[0-9,]+")

Hmm, that gives us a #N/A error… πŸ€”

Step 4

Turn this into an Array Formula and get the column of population numbers!

=ArrayFormula(REGEXEXTRACT(INDEX(IMPORTHTML("https://en.wikipedia.org/wiki/List_of_cities_proper_by_population","table",2),,4),"[0-9,]+"))

Google Sheets Complex Formula Step 4

We still have two problems to solve though: i) we need to convert the strings into actual numbers and ii) we need to fix the #N/A column heading…

Step 5

We can multiply by 1 (see the “*1” at the end of our formula), which coerces those text strings into actual numbers.

=ArrayFormula(REGEXEXTRACT(INDEX(IMPORTHTML("https://en.wikipedia.org/wiki/List_of_cities_proper_by_population","table",2),,4),"[0-9,]+") * 1)

Google Sheets Complex Formula Step 5

Step 6

Use the IFERROR function to fix that pesky #N/A error at the top of our column heading, and replace the #N/A with the word “Population”:

=ArrayFormula(IFERROR(REGEXEXTRACT(INDEX(IMPORTHTML("https://en.wikipedia.org/wiki/List_of_cities_proper_by_population","table",2),,4),"[0-9,]+")*1,"Population"))

Nice, now we have our population column as numbers:

Complex Formula using IFERROR in Google Sheets

Step 7

Pick the other columns we want, by wrapping the IMPORTHTML function with a QUERY function.

Note that we have to use the Col1 notation rather than the column letter in our Select statement, since we’re nesting another function as our data source in the QUERY function.

We also use the QUERY function rather than the INDEX function because we want to return multiple columns this time, which the INDEX function can’t do.

=QUERY(IMPORTHTML("https://en.wikipedia.org/wiki/List_of_cities_proper_by_population","table",2),"SELECT Col2, Col8",1)

Google Sheets Complex Formula Step 7

Step 8

All that’s left is to join these two ranges using the curly bracket notation, like this:

={

QUERY(IMPORTHTML("https://en.wikipedia.org/wiki/List_of_cities_proper_by_population","table",2),"SELECT Col2,Col8",1)
,
ArrayFormula(IFERROR(REGEXEXTRACT(INDEX(IMPORTHTML("https://en.wikipedia.org/wiki/List_of_cities_proper_by_population","table",2),,4),"[0-9,]+") * 1,"Population"))

}

(Shown with line breaks to illustrate the two ranges.)

Ok, we’re done πŸ€ͺ

The output is:

Google Sheets IMPORTHTML output

Example 2: Deconstructing With The Onion Method

If you’re trying to understand complex formulas in Google Sheets that someone else has shared with you, you can still approach it with this Onion Method.

Simply peel back the layers until you reach the innermost function. Copy that into a new cell and start from the inside and work out, building up to the full formula again.

Let’s see an example.

Suppose we’re given this worksheet with US State names:

dataset of US State Names

And we’re also given this formula:

=ArrayFormula(INDEX(A1:A20,MODE(MATCH(A1:A20,A1:A20,0))))

which gives an output of Texas.

But how does this formula work?

Applying The Onion Method, we peel back the layers to the core function, and then build it up in steps again.

Step 1

In a new cell, add the innermost MATCH function:

=MATCH(A1:A20,A1:A20,0)

Step 2

=ArrayFormula(MATCH(A1:A20,A1:A20,0))

which outputs an array of the position of the first occurrence of the words in column A. We see a 2 next to every occurrence of Texas for example, because the first time it occurred was in position 2.

Step 3

Now, we wrap it with the MODE function to find the most frequently occurring position:

=ArrayFormula(MODE(MATCH(A1:A20,A1:A20,0)))

By definition, the MODE function takes a range of numbers for an input and finds the most commonly occurring value.

However, what happens if we have a range of text values and want to find the most frequent?

In this case, the MATCH has been used to create a range of numbers for the MODE function.

By now, we’ve probably deduced that this formula finds the most frequent word in a list.

Step 4

Finally, we can retrieve the actual text value, i.e. the most frequent State name, by adding the INDEX function to get the full original formula, like this:

=ArrayFormula(INDEX(A1:A20,MODE(MATCH(A1:A20,A1:A20,0))))

This will give the output Texas in this specific example.

Nice!

Template For Your Use

Click here to open a read-only copy of the template >>

This template contains both examples from this tutorial.

To make your own editable copy, please go to File > Make a copy… under the File menu.

Conclusion

The Onion Method is a framework that allows you to approach complex formulas in a systematic way.

Even if you’re presented with an “impossible” challenge to answer or an “impossible” formula to decipher, just follow this framework. If required, peel back the layers and then work from the inside out in an incremental fashion.

You’ll be amazed at how quickly your understanding of challenging formulas broadens and deepens. You’ll encounter and understand brand new functions that you’ve never heard of before. Plus, you’ll find out all sorts of secret tricks with existing formulas.

Who knows, you might even cry tears of joy instead of despair…

I’ll leave you with this quote from businesswoman Belinda Johnson:

I like cutting through complexity and trying to get to the kernel of an idea.

Formula Challenge #2: Matching Terms

(This Formula Challenge originally appeared as part of Google Sheets Tip #52, my weekly newsletter, on 27 May 2019.

Sign up here so you don’t miss out on future Formula Challenges!

Find all the Formula Challenges archived here.)

Your Challenge

Start with this small data table in your Google Sheet:

Formula Challenge dataset

Your challenge is to create a single-cell formula that takes a string of search Terms and returns all the Results that have at least one matching term in the Terms column.

For example, this search (in cell E2 say)

Raspberries, Orange, Apple

would return the results (in cell F2 say):

One
Two
Five
Six
Seven
Nine

like this (where the yellow is your formula):

Formula Challenge expected results

Check out the ready-made Formula Challenge template.

The Solution

Solution One: Using the FILTER function

=FILTER(A2:A11,REGEXMATCH(B2:B11,JOIN("|",SPLIT(E2,", "))))

or even:

=FILTER(A2:A11,REGEXMATCH(B2:B11,SUBSTITUTE(E2,", ","|")))

These elegant solutions were also the shortest solutions submitted.

There were a lot of similar entries that had an ArrayFormula function inside the Filter, but this is not required since the Filter function will output an array automatically.

How does this formula work?

Let’s begin in the middle and rebuild the formula in steps:

=SPLIT(E2,", ")

splits out the three fruits in cell E2 into separate cells:

Raspberries    Orange    Apple

Next, join them back together with the pipe “|” delimiter with

=JOIN("|",SPLIT(E2,", "))

so the output is now:

Raspberries|Orange|Apple

Then bring the power of regular expression to the table, to match the data in column B. The pipe character means “OR” in regular expressions, so this formula will match Raspberries OR Orange OR Apple in column B:

=REGEXMATCH(B2:B11,JOIN("|",SPLIT(E2,", ")))

On its own, this formula will return a #VALUE! error message. (Wrap this with the ArrayFormula function if you want to see what the array of TRUE and FALSE values looks like.)

However, when we put this inside of a FILTER function, the correct array value is passed in:

=FILTER(A2:A11,REGEXMATCH(B2:B11,JOIN("|",SPLIT(E2,", "))))

and returns the desired output. Kaboom! πŸ’₯

Solution Two: Using the QUERY function

=QUERY(A2:B11,"select A where B contains '"&JOIN("' or B contains '",SPLIT(E2,", "))&"'")

As with solution one, there is no requirement to use an ArrayFormula anywhere. Impressive!

This formula takes a different approach to solution one and uses the QUERY function to filter the rows of data.

The heart of the formula is similar though, splitting out the input terms into an array, then recombining them to use as filter conditions.

=JOIN("' or B contains '",SPLIT(E2,", ",0))

which outputs a clause ready to insert into your query function, viz:

Raspberries' or B contains 'Orange' or B contains 'Apple

The QUERY function uses a pseudo-SQL language to parse your data. It returns rows from column A, whenever column B contains Raspberries OR Orange OR Apple.

Wonderful!

Click here to open a read-only version of the solution template (File > Copy to make your own editable copy).

I hope you enjoyed this challenge and learnt something from it. I really enjoyed reading all the submissions and definitely learnt some new tricks myself.

SPLIT function caveats

There are two dangers with the Split function which are important to keep in mind when using it (thanks to Christopher D. for pointing these out to me).

Caveat 1

The SPLIT function uses all of the characters you provide in the input.

So

=SPLIT("First sentence, Second sentence", ", ")

will split into FOUR parts, not two, because the comma and the space are used as delimiters. The output will therefore be:

First    sentence    Second    sentence

across four cells.

Caveat 2

Datatypes may change when they are split, viz:

=SPLIT("Lisa, 01",",")

gives an output of

Lisa    1

where the string has been converted into a number, namely 1.

See the other Formula Challenges here.

Formula Challenge #1: Repeating Images with Array Formulas

Introduction

I firmly believe that one of the most effective and rewarding ways to learn a skill is through practical application.

Solving problems you don’t know the answer to is arguably the best way to do this.

And that’s the idea behind these Formula Challenges.

I’ll post a challenge in my Monday newsletter — a question to be solved with formulas in Google Sheets — and a week later share solutions, both my own and those submitted by readers.

I’ll archive the challenges and solutions on my website here.

(This first Formula Challenge originally appeared in my Google Sheets Tips newsletter, on 25 February 2019.

Sign up here so you don’t miss out on future Formula Challenges!)

The Challenge

Start with a straightforward IMAGE function in cell A1, like this:

=IMAGE("https://www.google.com/favicon.ico")

Google Sheets Image Formula

Your Challenge

Your challenge is to modify the formula in cell A1 only, to repeat the image across multiple columns (say 5 as in this example), so it looks like this:

multiple images in Google Sheets

Rules

You’re only allowed to use a single formula in cell A1.

The problem is that the IMAGE function can’t be nested inside a REPT function, so you have to get a bit more creative.

The Solution

Solution One: using ROW or COLUMN counts

=ArrayFormula(IF(COLUMN(A:E),IMAGE("https://www.google.com/favicon.ico")))

How does this formula work?

The combination of ArrayFormula with COLUMN(A:E) will output an array of numbers 1 to 5: {1,2,3,4,5}

The IF statement treats the numbers as TRUE values, so prints out the image 5 times. For brevity, we can omit the FALSE value of the IF statement, since we don’t call it.

Solution Two: using REPT inside the IMAGE formula!

=ArrayFormula(IMAGE(SPLIT(REPT("https://www.google.com/favicon.ico"&"|",5),"|")))

How does this formula work?

As mentioned, the REPT function doesn’t work when wrapped around the IMAGE function. However, flip them around, with the REPT inside the IMAGE function, and it does work!

In other words the IMAGE function accepts arrays of URLs as an input.

Start with this formula in cell A1, which creates a single string of joined URLs, with a pipe ( | ) delimiter between them:

=ArrayFormula(REPT("https://www.google.com/favicon.ico"&"|",5))

Now, split these into an array of 5 separate URLs:

=ArrayFormula(SPLIT(REPT("https://www.google.com/favicon.ico"&"|",5),"|"))

Finally, wrap this with the IMAGE function to get the five images in a row:

=ArrayFormula(IMAGE(SPLIT(REPT("https://www.google.com/favicon.ico"&"|",5),"|")))

What I like about this solution is that you could put the number 5 into a different cell and reference it, so that you can easily change how many times the image is repeated.

You could even embed another formula to calculate how many times to repeat the image πŸ˜‰

See the other Formula Challenges here.

In Pursuit Of A Dream

As I’ve grown, my values have changed and evolved.

Things that mattered to me in my twenties and early thirties don’t matter so much now.

As each year passes, what matters to me becomes clearer. A simple life, with a focus around family, regular outdoor exercise, and a good work routine is what I’m looking for.

(Honestly, I think this guy had it figured out πŸ˜‰ )

For the past few years, my wife and I have nurtured a shared dream of moving our family to a small mountain town.
Continue reading In Pursuit Of A Dream

10 Coding Tips For Beginners With Apps Script

These 10 coding tips will help you develop good practices early in your coding journey.

Learning a programming language is hard. The amount of information feels overwhelming at first. However, by focussing on a few key concepts and techniques, you can make rapid progress.

Use these 10 coding tips to learn Google Apps Script effectively:

1. Make Your Code Understandable

Use plenty of white space and comments in your Apps Script code:

// get data out of spreadsheet
function getData() {
    // code here...
}

Don’t worry about trying to make your code concise when you’re learning, better you understand it when you come back to look at it the next day or next week.

2. Use these keyboard shortcuts when working in the editor

Use these keyboard shortcuts to work more efficiently in the Apps Script editor. These simple shortcuts are SO useful when you’re working with Apps Script that I implore you to take a few minutes today to try them out!

Auto Comment

Auto Comment with:

Ctrl + /

This works on individual lines or blocks of your Apps Script code.

Apps script comment shortcut

Move code up and down

Move code up and down with:

Alt + Up/Down

If you find yourself wanting to move code around, this is SUPER handy.

Apps script shortcut to move code up and down

Tidy up indentation

Tidy up indentation with:

Tab

Keeping your code properly indented makes it much easier to read and understand. This handy shortcut will help you do that. It’s especially useful if you’ve copied code from somewhere else and the indenting is all higgledy-piggledy.

Apps script indentation shortcut

Bring up the code auto-complete

Bring up the Apps Script code auto-complete with:

Ctrl + Space

(or Ctrl + Alt + Space on Chromebook)

How many times have you been typing a class or method, made a spelling mistake only to see the helpful auto-complete list disappear? Bring it back with Ctrl + Space (or Ctrl + Alt + Space on Chromebook).

Apps script auto complete shortcut

3. Record a macro and look at the code

If you’re not sure how to write something in code, or you’re trying something new, record a Google Sheets Macro for that action and review the code.

The macro tool doesn’t always generate the most concise code, but it will give you helpful clues on how to do certain tasks. You can copy snippets of code and utilize them in your own code.

4. Log Everything with Google script logger

Use the Google script logger Logger.log() method liberally when you’re getting started.

It prints out the values of whatever you “log”, for example the output of a function call. It’s super helpful for you to see what’s going on inside your script at different stages.

You can also add notes like this:

Logger.log("Hey, this function X just got called!");

If you see this in your logs, then you know that function X was called.

This is probably the most useful tip from these 10 coding tips!

5. Understand These Four Fundamental Concepts

i) Variables

Variables are placeholders for storing data values. You create variables with the var notation and assign values with a single equals sign.

For example, the following expression sets the variable counter to have a value of 0. Anytime you use counter in your code, it will have the value 0, until you change it.

var counter = 0;

ii) Functions

Functions are blocks of code designed to perform a specific task. A function is run (executed) when something calls it (invokes it).

Functions can be declared (created) with the word function followed by the function name, which is getData in the following example:

// get data out of spreadsheet
function getData() {
    // code here...
}

The brackets immediately after the function name are required, and are used to hold optional arguments, in a similar way to how functions are used in Google Sheets.

iii) Arrays

Arrays hold multiple values in a single variable, using a square bracket notation. The order of the values is important. Items are accessed by calling on their position in the array. One other thing to note: the array index starts from 0, not 1!

The following expression creates a new array, called fruitsArray, with three elements in positions 0, 1 and 2.

var fruitsArray = [ "apple", "banana", "pear" ];

iv) Objects

Objects can hold multiple values too, but think of them as properties belonging to the object. They are stored in key/value pairs. For example, here is an object, stored in a variable called book, which has two key/value property pairs:

var book = {
  "title": "Apps Script Book",
  "author": "Ben Collins"
}

The order of the pairs does not matter when you write out objects. The values are accessed by calling on the key names.

Obviously there’s a lot more to Apps Script than just these four concepts, but understanding Variables, Functions, Arrays and Objects, and how to work with them, will go a long way towards you creating functional Apps Script programs of your own.

6. Understand the Google Sheets Double Array Notation

This is really, really key to using Apps Script to work with Google Sheets. Once you understand the double array notation for Google Sheets data, you open up a huge range of opportunities for extending your Google Sheets work. Spend enough time with this topic, and it’ll become as familiar as the regular A1 notation in Sheets.

Coding tips for Apps Script
On the left, Google Sheets data. On the right, Google Apps Script data.

7. Learn basic loops

The For Loop

Start with the basic for loop to understand how loops work.

It lays bare the mechanics of the loop, showing the starting number, how many times to loop and whether you’re increasing the loop counter or decreasing it.

for (var i = 0; i < 10; i++) {
    Logger.log(i);
}

The ForEach Loop

Next up, take some time to learn the more modern looping method: the forEach loop.

This hides the loop mechanics, which makes for cleaner, more readable code. It’s really easy to work with once you get the hang of it.

array.forEach(function(item) {
    Logger.log(item);
});

Basically it grabs all the data from your array and loops over each item in turn. You can do something, by applying a function, to each item during each loop of the array.

8. Understand how Google Sheets <--> Apps Script Transfer Data

Understand how data is passed back and forth between Google Sheets and Apps Script, and how to optimize for that.

Calculations in Google Sheets are done in your browser and are fast. Similarly, calculations done in Apps Script on the Google servers are lightning fast. But passing data back and forth from Sheet to Apps Script or vice versa, oh boy! That’s slow in comparison. (We’re still talking seconds or minutes here, but that’s slow in computing terms.)

To illustrate, here’s a script that retrieves values one cell at a time, performs a calculation in Apps Script and sends the single cell answer back to the Google Sheet. It performs this for one hundred numbers (shown in real time):

Slow data transfer Sheets to Scripts

Contrast that to the equivalent calculation where the script grabs all one hundred numbers in one, performs the calculations and pastes them back en masse, in one go:

Coding tips - fast data transfer from Apps Scrip to Sheets

Looks almost instantaneous to the human eye. So much faster!

Here’s another image to summarize this optimization process:

Coding tips for Sheets to Apps Script data best practice
Slide taken from the Automation With Apps Script course

Try to minimize the number of calls you make between your Apps Script and your Google Sheets.

9. Use the Documentation

The Apps Script documentation is your friend.

It might feel overwhelming at first, but persevere and spend time there. Most likely you’ll find something of value to help you solve your current issue.

It’s full of both code examples and a comprehensive reference, so you can look up the precise type of the return value of function X.

10. Ask for help

The final tip of the 10 coding tips is to not be afraid to ask for help when you get stuck.

I always advocate spending time trying to solve your problems yourself, but past a certain point it’s diminishing returns.

Know when to stop banging your head against the wall and try searching for or asking for help in one of these two places:

Google Apps Script Community Group

Stack Overflow Apps Script Tag

Want to learn more?

Got these 10 coding tips dialed? Want to keep learning. Here are some more resources to try:

Beginner Tutorials

πŸ‘‰ Guide to simple automation with Google Sheets Macros

Macros are small Apps Script programs which the computer records for you. They’re a gentle way to start with Apps Script.

πŸ‘‰ Google Apps Script: A Beginner’s Guide

Online courses

I’ve created two high quality, online courses teaching Apps Script from the ground up. They’re the best way to learn Apps Script in the shortest amount of time.

The first course, Apps Script Blastoff, is designed to take you from 0 to 20 and get you started on your Apps Script journey.

The follow-up course, Automation With Apps Script, is designed to take you from 10 to 100 (or wherever you want to go!) and focusses on how to automate workflows in G Suite and connect to external APIs. This course is available for enrollment twice per year, and the next open enrollment is in early 2020.
